Case Qty: 12 Rolls
Roll Length: 30'
Case Weight: 7 lbs
Roll Length: 150'
Case Weight: 17 lbs
PRODUCT INFORMATION GUIDE
Application(s): Our Engineer Grade reflective sheeting is a high quality, durable, enclosed lens retroreflective material. This reflective sheeting offers exceptional value for permanent traffic signage applications. Meets applicable requirements for engineer grade sheeting applications for Type 1 retroreflective sheeting as set forth in ASTM D 4956.
Adhesive: Permanent Pressure Sensitive (Class 1)
Face Film: High Gloss
Liner: White Polyethylene Coated Paper
Tape Application: Minimum application temperature 4C (40F) Surface must be clean and free from dust, dirt, oil, wax, silicone.
Cleaning: Clean tape surface with a mild soap and rinse with fresh water.
Shelf Life: One year, when stored at 73F (23C), 50% +/- 5% relative humidity.
Outdoor Durability: 7 years when properly processed and applied (vertical)
Operational Temp: (-40C to 82C) -40F to 180F
Typical Film Caliper: 4.5 - 5.5 mils
Specifications: Meets all other requirements set forth in ASTM D 4956 including shrinkage, flexibility, liner removal, adhesion, impact resistance, specular gloss and outdoor weathering.
Photometric Performance: Exceeds Types III and IV values per ASTM D 4956. Minimum Coefficient of Retroreflectivity (RA) (cd/lx/m2)
This data is based on typical results achieved. It is the sole responsibility of the buyer or user to ensure that the product is suitable for any proposed end use or application and to ensure proper cleaning of the substrate to which it will be applied. This data in no way constitutes a specification, nor should it be seen as a recommendation for use. We accept no liability for any loss, damage or injury resulting from the use of these products or data. Feb 2005.
